晶體管 - 江蘇長(cháng)晶科技股份有限公司

晶體管

Part Number	Download	Circuit	Status	Polarity	PCM (W)	IC (A)	VCBO (V)	VCEO (V)	VEBO (V)	hFE Min	hFE Max	hFE@VCE (V)	hFE@IC (A)	VCE(sat) (V)	VCE(sat)@IC (A)	VCE(sat)@IB (A)	Package
Reset Reset All			Active OK Reset	NPN PNP OK Reset	OK Reset	OK Reset	OK Reset	OK Reset	OK Reset	OK Reset	OK Reset	OK Reset	OK Reset	OK Reset	OK Reset	OK Reset	DFNWB3x2-8L SOT-223 TO-126 TO-220-3L TO-220F TO-251 TO-252-2L OK Reset

2SB1202			Active	PNP	1	-3	-60	-50	-6	100	560	-2	-3	-0.07	-2	-0.1	TO-252-2L
D882			Active	NPN	1.25	3	40	30	6	60	400	2	1	0.5	2	0.2	TO-126
2SA1012			Active	PNP	1.25	-5	-60	-50	-5	70	240	-1	-1	-0.4	-3	-0.15	TO-252-2L
2SB776			Active	PNP	1	-3	-50	-50	-5	100	400	-2	-1	-0.5	-2	-0.2	TO-126
2SB1370			Active	PNP	2	-3	-60	-60	-5	100	320	-5	-0.5	-1.5	-2	-0.2	TO-220F
2SB834			Active	PNP	1.5	-3	-60	-60	-7	60	200	-5	-0.5	-1	-3	-0.3	TO-220F
2SD1499			Active	NPN	2	5	100	100	5	60	200	5	1	2	3	0.3	TO-220F
2SD1761			Active	NPN	2	3	80	60	5	60	320	5	0.5	1	2	0.2	TO-220F
2SD2012			Active	NPN	2	3	60	60	7	100	320	5	0.5	1	2	0.2	TO-220F
2SD2061			Active	NPN	2	3	80	60	5	100	320	5	0.5	1	2	0.2	TO-220F
2SD2137			Active	NPN	2	3	60	60	6	70	320	4	1	1.2	3	0.375	TO-220F
3CA1837			Active	PNP	1.5	-1	-230	-230	-5	100	320	-5	-0.1	-1.5	-0.5	-0.05	TO-220F
3DA4793			Active	NPN	1.5	1	230	230	5	100	320	5	0.1	1.5	0.5	0.05	TO-220F
KTA1659A			Active	PNP	2	-1.5	-180	-180	-5	70	240	-5	-0.1	-1.5	-0.5	-0.05	TO-220F
KTB1366			Active	PNP	2	-3	-60	-60	-7	60	200	-5	-0.5	-1	-2	-0.2	TO-220F
KTB1367			Active	PNP	2	-5	-100	-100	-5	40	240	-5	-1	-2	-4	-0.4	TO-220F
KTC4370A			Active	NPN	2	1.5	180	180	5	70	240	5	0.1	1.5	0.5	0.05	TO-220F
KTD2058			Active	NPN	2	3	60	60	7	60	200	5	0.5	1	2	0.2	TO-220F
2SD2396			Active	NPN	2	3	80	60	6	400	2000	4	0.5	0.8	2	0.05	TO-220F
KTC2026			Active	NPN	2	3	60	60	7	100	300	5	0.5	1	2	0.2	TO-220F
